Media technology overview

Below you will find an overview of the media technology devices that can be borrowed, including notes and partly operating instructions on the individual devices.

The page is still under construction and will be gradually filled with info about the devices.

  • Projectors

    Title Location Other
    Casio XJ-A242 Einsteinstraße 60 Manual (PDF) (de)
    Casio XJ-F210WN Einsteinstraße 60 Manual (PDF) (de)
    Short Manual (PDF) (de)
    Casio XJ-M256 Einsteinstraße 60 Manual (PDF) (de)
    Optoma EW766 Einsteinstraße 60 Manual (PDF) (de)



    Casio XJ-A242

    The Casio XJ-A242 is a projector with a resolution of 1280 x 800 pixels (WXGA), 2x optical zoom and a projection ratio of 1.15-2.30:1 (Example: for a 1 meter wide image, the projector must be placed at a distance of 1.15-2.3m from the projection surface).

    Interfaces:

    •         Computer: 1x 15 pin D-Sub (VGA)
    •         Digital input: 1x HDMI connector
    •         Video/Audio: Composite: 1x 3.5 mm mini jack for audio input and output
    •         Component Video: Opt. adapter via RGB mini D-Sub 15 pin

    Casio XJ-A242
    © Casio Europe GmbH

    Casio XJ-F210WN

    The Casio XJ-F210WN is a projector with a resolution of 1280 x 800 pixels (WXGA), 1.5x optical zoom and a projection ratio of 1.32- 1.93:1 (Example: for a 1 meter wide image, the projector must be placed at a distance of 1.32-1.93m from the projection surface).

    Interfaces:

    • Computer: 1x 15 pin D-Sub (VGA)
    • Digital input: 2x HDMI terminal
    • Video input: S-Video terminal / RCA pin terminal (composite)
    • Audio:
      • Input Terminal: 1x 3.5 mm Stereo Mini Jack; RCA Pin Terminal (composite)
      • Output terminal: 1x 3.5 mm stereo mini jack (variable audio output)
    • Microphone input: 3.5 mm monoaural mini jack
    • Control Inputs:
      •  RS-232C (D-Sub 9pin)
      • LAN RJ-45

    Casio XJ-F210WN
    © Casio Europe GmbH

    Casio XJ-M256

    The Casio XJ-M256 is a projector with a resolution of 1280 x 800 pixels, 1.5x optical zoom and a projection ratio of 1.32-1.93:1 (Example: for a 1 meter wide image, the projector must be placed at a distance of 1.32-1.93m from the projection surface).

    Interfaces:

    • Computer Inputs: 1 x 15-pin D-sub (VGA)
    • Digital input: HDMI port
    • Video:
      • S-Video terminal x 1
      • RCA pin terminal (composite) x 1
    • Component Video: Optional adapter to fit 15-pin RGB mini D-sub (VGA)
    • Audio:
      • Inputs: 2 x 3.5 mm stereo mini jack
      • RCA: pin terminal (L/R) x 1
      • Output: 1 x 3.5 mm stereo mini jack

    Casio XJ-M256
    © Casio Europe GmbH

    Optoma EW766

    The Optoma EW766 is a projector with a resolution of 1280 x 800 pixels, 1.6x manual zoom and a projection ratio of 1.55-2.48:1 (example: for a 1-meter wide image, the projector must be placed at a distance of 1.55-2.48m from the projection surface).

    Connections:

    • HDMI in
    • DVI-D with HDCP in
    • 2 x D-sub 15 pin in 1 x out
    • S-Video in
    • Cinch video in
    • RS232C Din 9 pin
    • RJ45
    • USB
    • 12V Trigger out

    Optoma EW766
    © OPTOMA Deutschland GmbH
  • Camera

    Title Location Others
    Logitech PTZ 2 Pro Einsteinstraße 60 Manual



    Logitech PTZ 2 Pro

    The Logitech PTZ 2 Pro is a high-resolution USB camera with HD 1080p resolution and pan, tilt and 10x zoom function.
    The USB port makes it quick and easy to connect the camera to laptops or computers. The remote control makes it easy to adjust the camera remotely for your needs.
    We offer two different packages along with the camera:

    • Logitech PTZ 2 Pro + Tripod + USB extension 5m.
    • Logitech PTZ 2 Pro+Tripod+USB Extender 5m+Table Mic
      • This package includes a Jabra Speak 510 table mic, if this package is ever out of stock, please book a table mic separately if needed. A description of the Jabra Speak 510 can be found in the "Microphones" section.

    Logitech PTZ 2 Pro
    © Logitech Europe S.A.
  • Speakers

    Title Location Others
    Bose Power Lifestyle white Einsteinstraße 60
    the box MBA120W Einsteinstraße 60 Manual (PDF)



    Bose Power Lifestyle white

    Description will be provided later.

    the box MBA120W

    the box 120W is a battery-powered mobile loudspeaker with radio microphone handheld transmitter (incl. transport trolley and IR remote control). The built-in battery lasts approx. 4 hours in music mode and approx. 6 hours in voice mode.

    the box MBA120W
    © Thomann GmbH
  • Screen

    Title Location Others
    Screen 2 Celexon 1,6m width Einsteinstraße 60 Manual (PDF) (de)



    Screen 2 Celexon 1,6m width

    The Celexon screen is a mobile screen with a presentation size of 1.60m x 1.20m. Due to the compact design, it can be set up and taken down in no time.

    Screen 2 Celexon 1,6m width
    © visunext International GmbH & Co. KG
  • Microphones

    Title Location Others
    Jabra Speak 510 Einsteinstraße 60 Short manual Jabra Speak 510
    Jabra Speak 710 Einsteinstraße 60 Short manual Jabra Speak 710
    Sennheiser E825 S Einsteinstraße 60 Manual Sennheiser E825-S (de)
    Quick Guide E825-S (de)



    Jabra Speak 510

    The Jabra 510 is a 360-degree microphone that can be used for conference calls by connecting it via USB or Bluetooth®. Due to the clear sound and small size, it can also be used as a mobile speaker.

    Jabra Speak 510
    © Jabra GN Audio A/S

    Jabra Speak 710

    The Jabra Speak 710 is a 360-degree microphone that enables conference calls with up to 6 participants (manufacturer's specification). By pairing two Jabra Speak 710, conferences with up to 12 participants (manufacturer's specification) can also be realized in a conference room.
    The device can be connected to a laptop or smartphone within seconds via USB or Bluetooth®, and its omni-directional microphone ensures perfect sound wave coverage from all directions.


    Jabra Speak 710
    © Jabra GN Audio A/S

    Sennheiser E825 S

    The Sennheiser E825-S is a versatile wired handheld microphone with cardioid polar pattern.
    An XLR cable is included to connect the microphone.

    Sennheiser E825 S
    © Sennheiser electronic GmbH & Co. KG
  • Others

    Title Location Others
    Beyerdynamic Unite Set Einsteinstraße 60 Manual Unite RP
    Manual Unite TP
    reflecta DigitDia 7000 Magazinscanner Einsteinstraße 60 Manual (PDF)



    Beyerdynamic Unite Set

    The Beyerdynamic Unite Set is a set for mobile hearing assistance, consisting of the hearing aid receiver (Unite RP), the hearing aid transmitter incl. clip-on microphone (Unite TP), headphones (DTS2), an induction loop (Synexis IL200) and a matching USB-C charger incl. charging cable.
    A quick reference guide for operation is included in the set.
    More detailed instructions for the RP and TP are linked in the table above.

    Beyerdynamic Unite Set
    © beyerdynamic GmbH & Co. KG

    Reflecta DigitDia 7000

    The Reflecta Digit Dia 7000 is a magazine scanner that can scan slides with resolutions up to 10000 DPI and a maximum density of 4.2.
    Compatible magazines:
    - CS-Magazin
    - Universal-Magazin DIN 108
    - LKM-Magazin
    - Paximat-Magazin

    Reflecta DigitDia 7000
    © reflecta® gmbh
