Mathematical Models in Tomography

In the description of the mathematical models we restrict ourselves to those features which are important for the mathematical scientist. For physical and medical aspects see [35], [6], [32].

(a) Transmission CT.

This is the original and simplest case of CT. In transmission tomography one probes an object with non diffracting radiation, e.g. x-rays for the human body. If is the intensity of the source, a(x) the linear attenuation coefficient of the object at point x, L the ray along which the radiation propagates, and I the intensity past the object, then

In the simplest case the ray L may be thought of as a straight line. Modeling L as strip or cone, possibility with a weight factor to account for detector inhomogeneites may be more appropriate. In (2.1) we neglegt the dependence of a from the energy (beam hardening effect) and other non linear phenomena (e.g. partial volume effect).

The mathematical problem in transmission tomography is to determine a from measurements of I for a large set of rays L. If L is simply the straight line connecting the source with the detector , (2.1) gives rise to the integrals

where dx is the restriction to L of the Lebesgue measure in . We have to compute a in a domain from the values of (2.2) where , run through certain subsets of .

For n = 2, (2.2) is simply a reparametrization of the Radon transform

where . Thus our problem is in principle solved by Radon's inversion formula

where

is the so-called backprojection and

with H the Hilbert transform [39]. In fact the numerical implementation of (2.4) leads to the filtered backprojection algorithm which is the standard algorithm in commercial CT scanners, see section 3.

For n = 3, the relevant integral transform is the x-ray transform

where and . admits a similar inversion formula as R, to wit

with K very similar to (2.6) and

where is the orthogonal projection onto . Unfortunately, (2.7) is not as useful as (2.4). The reason is that (2.7) requires g for all and , i.e. (2.2) has to be available for all , . This is not practical. Also, it is not necessary for unique reconstruction of a. In fact it can be shown that a can be recovered uniquely from (2.2) with sources on a circle surrounding supp(a) and . Unfortunately the determination of a in such an arrangement is, though uniquely possible, highly unstable. The condition of stability is the following: Each plane meeting supp(a) must contain at least one source [16]. This condition is obviously violated for sources on a circle. Cases in which the condition is satisfied include the helix and a pair of orthogonal circles. A variety of inversion formulae has been derived, see section 4.

If scatter is to be included, a transport model is more appropriate. Let be the density of the particles at x travelling (with speed 1) in direction . Then,

Here, is the probability that a particle at x travelling in direction is scattered in direction . Again we neglect dependence on energy. is the Dirac -function modeling a source of unit strength. (2.2a) holds in a domain of , and . Since no radiation comes in from outside we have

where is the exterior normal on at . (4.1) is now replaced by

The problem of recovering a from (2.8) in much harder. An explicit formula for a such as (2.4) has not become known and is unlikely to exist. Nevertheless numerical methods have been developed for special choices of [3], [7]. The situation gets even more difficult if one takes into account that, strictly speaking, is object dependent and hence not known in advance. (2.8) is a typical example of an inverse problem for a partial differential equation. In an inverse problem one has to determine the differential equation - in our case a, - from information about the solution - in our case (2.8c).

(b) Emission CT.

In emission tomography one determines the distribution f of radiating sources in the interior of an object by measuring the radiation outside the object in a tomographic fashion. Let again be the density of particles at x travelling in direction with speed 1, and let a be the attenuation distribution of the object. (This is the quantity which is sought for in transmission CT). Then,

This equation holds in the object region for each . Again there exists no incoming radiation, i.e.

while the outgoing radiation

is measured and hence known. (2.9) again constitutes an inverse problem for a transport equation. For a known, (2.9a-b) is readily solved to yield

Thus (2.9c) leads to the integral equation

for f. Apart from the exponential factor, (2.10) is identical - up to notation - to the integral equation in transmission CT. Except for very special cases - e.g. a constant in a known domain [52], [42] no explicit inversion formulas are available. Numerical techniques have been developed but are considered to be slow. Again the situation becomes worse if scatter is taken into account. This can be done by simply adding the scattering integral in (2.8a) to the right hand side of (2.9a).

What we have described to far is called SPECT (= single particle emission CT). In PET (= positron emission tomography) the sources eject the particles pairwise in opposite directions. They are detected in coincidence mode, i.e. only events with two particles arriving at opposite detectors at the same time are counted. (1.10) has to be replaced by

Thus PET is even closer to the case of transmission CT. If a is known, we simply have to invert the x-ray transform. Inversion formulas which can make use of the data collected in PET are available, see section 3.

The main problems in emission CT are unknown attenuation, noise, and scatter. For the attenuation problem, the ideal mathematical solution would be a method for determining f and a in (2.9) simultaneously. Under strong assumption on a (e.g. a constant in a known region [26], a affine distortion of a prototype [37], a close to a known distribution [8]) encouraging results have been obtained. Theoretical results based on the transport formulation have been obtained, even for models including scatter [43]. But a clinically useful way of determining a from the emission data has not yet been found.

Noise and scatter are stochastic phenomena. Thus, besides models using integral equations, stochastic models have been set up for emission tomography [48]. These models are completely discrete. We subdivide the reconstruction region into m pixels or voxels. The number of events in pixel/voxel j is a Poisson random variable whose mathematical expection is a measure for the activity in pixel/voxel j. The vector is the sought - for quantity. The vector of measurements is considered as realization of the random variable where is the number of events detected in detector i. The model is determined by the (n,m)-matrix whose elements are (event in pixel/voxel j detected in detector i)

where P denotes probability. We have . is determined from g by the maximum liklihood method. A numerical method for doing this is the EM (= expection maximation) algorithm. In its basic form it reads

where division and multiplication are to be understood component wise. The problem with the EM-algorithm is that it is only semi-convergent, i.e. noise is amplified at high iteration numbers. This is known as the checkerboard effect. Various suggestions have been made to get rid of this effect. The most exciting and interesting ones use ``prior information'' and attempt to maximize ``posterior likelihood''. Thus f is assumed to have a prior probability distribution, called a Gibbs-Markov random field , which gives preference to certain functions f [46], [21], [18]. Most prior simply add a penalty term to the likelihood function to account for correction between neighboring pixels and do not use biological information. However if is carefully chosen so that piecewise constant functions f with smooth boundaries forming the region of constancy are preferred then the noise amplification at high iteration numbers can be avoided. The question remains as to whether this conclusion will remain valid for function f which are assigned low probability by - or, more to the point - whether ``real'' emission densities f will be well-resolved by this Bayesian method. An ROC study (e.g. double-blind trials where radiologists are to find lesions from images produced by two different algorithms) concluded that maximum likelihood methods were superior to the filtered backprojection algorithm (see section 3) in certain clinical applications. The same type of study is needed to determine whether or not Gibbs priors will improve the maximum likelihoof reconstruction (stopped short of convergence to avoid noise amplification) on real data.

(c) Ultrasound CT

X-rays travel along straight lines. For other sources of radiation, such as ultrasound and microwaves, this is no longer the case. The paths are no longer straight, and their exact shape depends on the internal structure of the object. We can no longer think in terms of simple projections and linear integral equations. More sophisticated non linear models have to be used.

In the following we consider an object with refractive index n. We assume n = 1 outside the object. The object is probed by a plane wave

with wave number , the wave length, travelling in the direction . The resulting wave satisfies the reduced wave equation

plus suitable boundary conditions at infinity. The inverse problem to be solved is now the following. Assume that

is known outside . Determine f inside !

Uniqueness and stability of the inverse problem (2.12) has recently been settled [36]. However, stability is only logarithmic [2], i.e. a data error of size results in a reconstruction error . Numerical algorithms did not emerge from this work.

Numerical methods for (2.12) are mostly based on linearizations, such as the Born and Rytov approximation [13]. In order to derive the Born approximation, one rewrites (2.12a) as

where G is an appropriate Green's function. For n = 3, we have

The Born approximation is now obtained by assuming in the integral in (2.13). With this approximation, (2.12b) reads

This is a linear integral equation for f, valid for all x outside the object and for all measured directions .

Numerical methods based on (2.15) - and a similar equation for the Rytov approximation - have become known as diffraction tomography. Unfortunately, the assumptions underlying the Born- and Rytov approximations are not satisfied in medical imaging. Thus, the reconstructions of f obtained from (2.15) are very poor. However, we may use (2.15) to get some encouraging information about stability. For |x| large, (2.15) assumes the form

with the Fourier transform of f. (2.16) determines within a ball of radius from the data (2.12b) in a completely stable way. We conclude that the stability of the inverse problem (2.12) is much better than logarithmic. If the resolution is restricted to spatial frequencies below - which is perfectly reasonable from a physical point of view - then we can expect (2.12) to be perfectly stable.

So far we considered plane wave irradiation at fixed frequency, and we worked in the frequency domain. Time domain methods are conceivable as well. We start out from the wave equation

with the propagation speed c assumed to be 1 outside the object. With a source outside the object we consider the initial conditions

We want to determine c inside the object from knowing

for many sources and receivers outside the object. In the one dimensional case, the inverse problem (2.17) can be solved by the famous Gelfand-Levitan method in a stable way. It is not clear how Gelfand-Levitan can be extended to dimensions two and three. The standard methods use sources and receivers on all of the boundary of the object. This is not practical in medical imaging. However, for reduced data sets, comparable to those in 3D X-ray tomography, we do not know how to use Gelfand-Levitan, nor do we know anything about stability.

Of course one can always solve the nonlinear problem (2.17) by a Newton type method. Such methods have been developed [23], [30]. They suffer from excessive computing time and from their apparent inability to handle large wave numbers k.

(d) Optical tomography

Here one uses NIR (= near infra-red) lasers for the illumination of the body. The process is now described by the transport equation

for the density of the particles at flying in direction at time t. and b are the sought - for tissue parameters. The scattering kernel is assumed to be known. The source term f is under the control of the experimenter. Together with the initial and boundary conditions

(1.18a) has a unique solution under natural conditions on a, b, and f. As in (1.1) we pose the inverse problem. Assume that we know the outward radiation

can we determine one or both the quantities a, b?

There are essentially three methods for illuminating the object, i.e. for choosing the source term f in (2.18a). In the stationary case one puts where is a source point. is considered stationary, too. A second possibility is the light flash . Finally one can also use time harmonic illumination, in which case . This case reduces to the stationary case with a replaced by . In all three cases, the data function g of (2.18c) is measured at , possibly averaged over one or both of the variables , t.

Light tomography is essentially a scattering phenomenon. This means that the scattering integral in (2.18a) is essential. It can no longer be treated merely as a perturbation as in x-ray CT. Thus the mathematical analysis and the numerical methods are expected to be quite different from what we have seen in other types of tomography.

The mathematical theory of the inverse problem (2.18) is in a deplorable state. There exist some Russian papers on uniqueness [4]. General methods have been developed, too, but apparently they have been applied to 1D problems only [44]. Nothing seems to be known about stability. The numerical methods which have become known are of the Newton type, either applied directly to the transport equation or to the so-called diffusion approximation [5], [31]. The diffusion approximation is an approximation to the transport equation by a parabolic differential equation. Since inverse problems for parabolic equations are severely ill-posed, this approach is questionable. Higher order approximations [29], [20] are hyperbolic, making the inverse problem much more stable.

As an alternative to the transport equation one can also model light tomography by a discrete stochastical model [22]. In the 2D case, break up the object into a rectangular arrangement of pixels labelled by indices i, j with and . Attach to each pixel the quantities , , , meant to denote the probability of a forward, backward, rightward or leftward transition out of the pixel i, j with respect to the direction used to get into this pixel. For each pair of boundary pixels i, j and , let be the probability that a particle that enters the object at pixel i, j will eventually leave the object at pixel , . The problem is to determine the quantities , , , from the values of for all boundary pixels. Preliminary numerical tests show that this is possible, at least in principle. However, the computations are very time consuming. More seriously, they reveal a very high degree of instability.

(e) Electrical Impedance Tomography

Here, the sought-for quantity is the electrical impedance of an object . Voltages are applied via electrodes on , and the resulting currents at these electrodes are measured. With u the potential in , we have

Knowing many voltage - current pairs g, f on , we have to determine from (2.19).

Uniqueness for the inverse problem (2.19) has recently be settled [36]. Unfortunately, the stability properties are very bad [2]. Numerical methods based on Newton's method, linearization, simple backprojection, layer stripping have been tried. All these methods suffer from the severe ill-posedness of the problem. There seems to be no way to improve stability by purely mathematical means.

(f) Magnetic Resonance Imaging (MRI)

The physical phenomena exploited here is the precession of the spin of a proton in a magnetic field of strength H about the direction of that field. The frequency of this precession is the Larmor frequency where is the gyromagnetic ratio. By making the magnetic field H space dependent in a controled way the local magnetization (together with the relaxation times , ) can be imaged. In the following we derive the imaging equations [27].

The magnetization M(x,t) caused by a magnetic field H(x,t) satisfies the Bloch equation

Here, is the i-th component of M, and is the i-th unit vector i=1,2,3. The significance of , , become apparent if we solve (2.20) with the static field and with initial values . We obtain with

Thus the magnetization rotates in the -plane with Larmor frequency and returns to the equilibrium condition with speed controlled by in the -plane and by in the -direction.

In an MRI scanner one generates a field

where G and are under control. In the jargon of MRI, is the static field, G the gradient, and the radio frequency (RF) field. The input G, produces in the detecting system of the scanner the output signal

where B characterizes the detecting system. Depending on the choice of various approximation to S can be derived.

(i) is constant in the small interval and (Short pulse). In that case,

Choosing G constant for and zero otherwise we get for

where is the 3D Fourier transform of .

From here we can proceed in several ways. We can either use (2.23) to determine the 3D Fourier transform of and to compute by an inverse 3D Fourier transform. This requires to be known on a Cartesian grid, what can be achieved by a proper choice of the gradients or by interpolation. We can also evoke the central slice theorem to obtain the 3D Radon transform of by a series of 1D Fourier transforms. is recovered in turn by inverting the 3D Radon transform.

The main numerical problem in MRI is to reconstruct a function from inperfect measurements of its Fourier transform [34]. Not much been achied so far.

(ii) is the shaped pulse

where is a smooth positive function supported in . Then, with , the first to components of x, G, respectively, we have

where

with a function Q essentially supported in a small neighborhood of 0. (2.24) is the 2D analogue of (2.23). So we have again the choice between Fourier imaging (i.e. computing the 2D Fourier transform from (2.24) and doing an inverse 2D Fourier transform) and projection imaging (i.e. doing a series of 1D Fourier transforms in (2.24) and inverting the 2D Radon transform).

Some of the mathematical problems of MRI, e.g. interpolation in Fourier space, are common to other techniques in medical imaging. An interesting mathematical problem occurs if the magnets to not produce suffiently homogeneous fields [33]. It calls for the reconstruction of a function from integrals over slightly curved manifolds. Even though this is a problem of classical integral geometry it has not yet found a satisfactory solution.

(g) Vector Tomography

If the domain under consideration contains a moving fluid, then the Doppler shift can be used to measure the velocity u(x) of motion. Assume the time harmonic signal is transmitted along the oriented line L. This signal is reflected by particles travelling with speed in the direction of L as , where , c the speed of the probing signal, i.e. is the Doppler shift. Let be the Lebesgue measure of these particles on L which move with speed , i.e. , the tangent vector on L. Then the total response is

Thus S can be recovered from g by a Fourier transform. The problem is to recover u from S.

Not much is known about uniqueness. However, the first moment of S,

is similar to the Radon transform. One can show that curl u can be computed from Ru, and an inversion formula similar to the Radon inversion formula exists. Numerical simulations are given in [51].

(h) Tensor Tomography

As an immediate extension of transmission CT to non-isotropic media we consider a matrix valued attenuation , i, . We solve the vector differential equation

for the vector valued function . Let a be defined in a convex domain , and let , . Then, with a nonlinear map depending on a. The problem is to recover a in from the knowledge of for , . For n = 1 we regain (2.1). Applications of (2.25) for n > 1 have become known in photoelasticity [1], but applications to medicine are not totally out of question.

In a further extension we let a depend on the direction . Such problems occur in the polarization of harmonic electromagnetic and elastic waves in anisotropic media. In linearized form these problems give rise to the transverse x-ray transform

and to the longitudenal x-ray transform

(2.27) can easily be reduced to the (n-1)-dimensional x-ray transform in the plane . We only have to introduce the function . Then, (2.27) provides for all the line integrals of on . For (2.28), the situation is not so easy. We decompose a in its solenoidal and potential part, i.e.

It can be shown that can be recovered uniquely from (2.28), but is completely undetermined [47]. This is reminiscent of vector tomography.
